THE FLYING LIFE, SIMPLIFIED

Streamline your flight prep and enjoy your aircraft more with the GDL 60 datalink and PlaneSync ™ technology. It’s the “connected aircraft” solution that automatically updates your avionics databases 1 , logs flight/engine data and lets you remotely check fuel and systems status via your Garmin Pilot ™ smart-device app 2 .

יכולות עיקריות

• GDL 60 is the datalink that enables our PlaneSync technology to remotely connect with your avionics.
• Automatic downloads via 4G LTE cellular or Wi-Fi ® connectivity keep your avionics updated with the latest databases 1 .
• Got fuel for your trip? Check the Garmin Pilot app on your smart device for a real-time aircraft status 2 update 5 .
• Get a head start by preloading your flight plan into your mobile device, then upload the data to your compatible navigator at the airport.
• In flight, you can use Connext ® satellite services to interface portable devices and apps with your avionics.
• At journey’s end, your flight logs, EIS data and other info are securely uploaded 1 into cloud storage and can be optionally sent to integrated services for additional analysis.
• AUTOMATIC DATABASE UPDATES: Forget time-consuming manual updates via data card. Your GDL 60 offers database downloads directly to the aircraft 1 . You don’t need to be present for the process. Most databases will auto-synchronize across your avionics at power up.
• FLIGHT/ENGINE DATA LOGGING AND ANALYSIS: With compatible avionics, your aircraft’s GDL 60 datalink can transmit flight and engine log data automatically 1 to secure cloud storage or analysis services after landing. Connected services such as FlySto and Savvy Aviation can convert your flight data to actionable insights and easy-to-read dashboards so you can gain a deeper understanding of your flight and engine performance.

מפרט רשמי נבחר

• Width: 8.72"
• Height: 1.12"
• Depth: 4.00"
• Weight: 1.5 lbs
• Input voltage: 14/28Vdc
• Operating temperature range: -40C to +70C
• Maximum altitude: 55,000 ft
• Memory: 64 GB eMMC
• Environmental compliance: RTCA DO-160F
• Software compliance: RTCA DO-178B Level D (GDL 60 unit), Level E (cellular firmware)
• TSO compliance: TSO-C109
• Global Operation: Bands: LTE B1,2,3,4,5,7,8,12,18,19,20,25,26,28,38,39,40,41
• Transmit power: +25 dBm max
• Physical radios: 2 (one internal access point, one external client)
• Class: 802.11 b/g/n
• Frequency band: 2.4 GHz
• Transmit power: +17 dBm / 50 mW max
• BLUETOOTH standard: 4.2
• Frequency band: 2.4 GHz
• Power class: 2 +4 dBm / 2.5 mW max

זיהוי רשמי של מוצר Garmin

• יצרן: Garmin
• משפחת מוצר: GDL® 60 Datalink with PlaneSync™ Technology
• תצורה: GDL® 60 Datalink with PlaneSync™ Technology
• מק״ט / SKU: 010-02245-00

תצורה פעילה זו אומתה מול קטלוג Garmin Aviation בארה״ב בתאריך 2026-07-24. זמינות, התאמה לכלי הטיס, דרישות תקינה והתקנה יאומתו לפני האספקה.
