GDM 450R, Standard Kit

GDM 450R, Standard Kit

FLY WITH PRECISION DISTANCE MEASUREMENT

Designed for Part 23 general aviation aircraft, the GDM 450R remote-mount DME works with select Garmin integrated flight decks and displays to provide slant-range distance calculations relative to DME ground stations.

יכולות עיקריות

• REMOTE-MOUNT DME RADIO
• AUTOMATICALLY TUNES DME CHANNELS, BASED ON SELECTED NAV RADIO FREQUENCY
• OPTIONAL FREE SCAN CAPABILITY SEARCHES FOR DME STATIONS WITHIN RANGE 1
• CAN REFERENCE MULTIPLE STATIONS FOR OPTIONAL DME-DME NAVIGATION 1
• OFFERS AN ALTERNATIVE NAVIGATION SOURCE TO SATELLITE-BASED GPS
• MAXIMIZES RANGE WITH 250 WATTS OF TRANSMIT POWER
• THE DME SOLUTION FOR TODAY’S GA AIRCRAFT: GDM 450R DME is a modern digital radio, designed for installation in general aviation aircraft. It’s a remote-mount unit that follows the tuning of associated NAV radio(s).
• MULTICHANNEL OPERATION: GDM 450R can allow pilots to tune and track up to two separate DME frequencies. With an optional enablement and compatible avionics, the aircraft’s FMS 1 can automatically scan and tune up to three additional DME frequencies.

מפרט רשמי נבחר

• Operational temperature range: -45° C to +70° C
• Maximum operating altitude: 55,000 ft
• Installed height (including rack): 1.35" (34.3 mm)
• Installed width (including rack): 6.30" (160.0 mm)
• Installed depth to connector backshell: 11.62" (295.1 mm)
• Weight (unit only): 2.42 lbs (1.1 kg)
• Weight (with install rack, connector kit, and configuration module): 3.05 lbs (1.4 kg)
• 14 V Typical/Tx: 0.6 A
• 14 V Maximum/Tx: 0.8 A
• 28 V Typical/Tx: 0.3 A
• 28 V Maximum/Tx: 0.4 A
• Minimum sensitivity level: -90 dBm
• Maximum range (line of sight): 300 nautical miles
• DME channels: 5 (with compatible avionics)
• Nominal Transmit Power: 250 watts

תכולת האריזה

• GTR 450R
• Installation rack
• Backplate kit
• Product Information Manual

זיהוי רשמי של מוצר Garmin

• יצרן: Garmin
• משפחת מוצר: GDM 450R
• תצורה: Digital Remote-mount DME Radio
• מק״ט / SKU: 010-02620-31

תצורה פעילה זו אומתה מול קטלוג Garmin Aviation בארה״ב בתאריך 2026-07-24. זמינות, התאמה לכלי הטיס, דרישות תקינה והתקנה יאומתו לפני האספקה.
